Waterloo Regional charts & airport diagram

Waterloo Regional (ALO · KALO) in Waterloo, IA publishes 14 FAA charts, including 8 instrument approaches (ILS, RNAV (GPS), LOC, VOR). Every one links straight to the current FAA PDF. · Open on the map

All of Waterloo Regional — runways, frequencies, charts and live weather

PDF ↗

Lowest minimums here: ILS with vertical guidance · Every chart below links straight to the current FAA PDF.

What KALO publishes

Airport diagram

The FAA airport diagram for Waterloo Regional — runways, taxiways, ramps and hold short lines. Shown in the browser above; the FAA PDF ↗ is the authoritative copy.

Instrument approaches at KALO

Waterloo Regional has 8 published instrument approaches of 4 types (ILS, RNAV (GPS), LOC and VOR). 5 of them offer vertical guidance; ILS gives the lowest minimums.

Hot spots at KALO

2 hot spots drawn on the map, with the Chart Supplement’s description for each.

HS 1 The intersection of Twy B and Twy C outbound holding position markings for Rwy 12–30 and Rwy 18–36 are immediately after the split of Twy B and Twy C.
HS 2 Use caution when crossing Rwy 12–30 on Twy A. Int departures should also insure proper rwy alignment before departure.

Locations on the airport surface with a history of confusion or runway incursions — brief them against the diagram before taxi. Source: FAA Chart Supplement, reproduced verbatim on the 56-day cycle; the numbers match the circled HS markers on the diagram.

Takeoff, alternate and surface information

Takeoff minimums are published for KALO. Standard is 1 statute mile visibility for one and two engine aircraft (½ mile for more than two) unless this section says otherwise; Part 91 operators are not bound by them but the obstacle notes apply to everyone.
Non standard alternate minimums are published: if you file KALO as an IFR alternate, the required forecast is higher than the default 600-2 for precision or 800-2 for non precision approaches. Check the alternate rule tool.
Land and hold short operations (LAHSO) are conducted here. The plate lists which runway intersections and the available landing distance for each; a pilot may always decline a LAHSO clearance.

All 14 charts, as a list every plate with its direct FAA link

Airport documents 3

Approaches 8

Minimums 3

Frequently asked

Where can I get the KALO airport diagram?

The FAA publishes the Waterloo Regional airport diagram as part of the d-TPP (Digital Terminal Procedures Publication), reissued every 28 days. The current one is linked on this page, along with a full-page preview.

Does KALO have an instrument approach?

Yes. Waterloo Regional has 8 published instrument approaches: ILS, RNAV (GPS), LOC, VOR. At least one offers vertical guidance.

Are there hot spots at KALO?

Yes. The FAA publishes 2 hot spots at Waterloo Regional — locations on the airport surface with a history of confusion or runway incursions. Each one's Chart Supplement description is on this page, numbered the way the airport diagram marks it.

What is the lowest approach at KALO?

ILS to runway 12 is the approach type with the lowest published minimums at Waterloo Regional. It has vertical guidance, so it is flown to a decision altitude rather than a minimum descent altitude. Actual minimums vary by aircraft category and are on the plate.

More about KALO

Charts are the FAA d-TPP (d-TPP cycle 2609 (2026, cycle 9)) and Chart Supplement, reissued on the 28-day chart cycle and linked directly from the FAA. For planning and education only; always fly the current chart.
