Maxwell Air Force Base Private

Airport information

ICAO / IATA

KMXF / MXF

Coordinates

32.3829, -86.3658

Elevation

171 ft MSL

Magnetic variation

2W

Sectional chart

ATLANTA

Airport use

Private

Control tower

Yes

ARTCC

ATLANTA (ZTL)

Flight service (FSS)

ANNISTON

NOTAM facility

MXF

Attendance

MON-FRI 1400-0400Z++; SAT-SUN 1600-0000Z++

Beacon

S-white-green (SS-SR)

Segmented circle

No

Wind indicator

yes

Activated

1941/05

Distance from city

2 NW

Communication frequencies

Nearby navigation aids

Approaches

• ILS OR LOC/DME RWY 15 ↗
• RNAV (GPS) RWY 15 ↗
• TACAN RWY 15 ↗
• TACAN RWY 33 ↗

Minimums & Hot Spots

• TAKEOFF MINIMUMS ↗

VFR sectional

Open KMXF on the VFR sectional (SkyVector) ↗

Services

Bulk oxygen

NONE

Airframe service

NONE

Powerplant service

NONE

Other services

Cargo

Ownership & management

Remarks FAA

• JASU: 4(A/M32A-86D) 2(AM32-95)
• FUEL: A++
• TRAN ALERT: AIREVAC AND DV ACFT WILL BE GIVEN PRIORITY SVCG.
• RSTD: DUR BIRD WATCH COND CODE MODERATE AND SEVERE, AIRCREWS SHOULD REFER TO AP/1 FOR BASH HAZARD CONDITIONS AND RESTRICTIONS; AIRCREWS CAN OBTAIN CURRENT BIRD WATCH COND FR ATIS/PTD/TWR.
• RSTD: LANDING ZONE USE AUTHORIZED FOR C130 OR SMALLER ACFT WITH PAVED LANDING ZONE TRAINING REQUIREMENTS; REFERENCE AP/1 FOR PROCEDURE/RSTD. LANDING ZONE LDG RQR PPR. CTC AFLD MGMT OPS DSN 493-6961/62 OR C334-953-6961/62. ACFT TRANS DV TO KMXF OR GUNTER ANNEX CTC PTD 30 MIN PRIOR LDG.
• CAUTION: PRACTICE MISSED APCH IN VFR COND MAINT RWY HDG BLW 1200' TIL OVER DEP END OF RWY THEN IMMED RGT STD RATE TURN TO HDG 300 DEG TO AVOID DANNELLY FIELD.
• MISC: 1ST 2207' RWY 15 IS CONC & GROOVED, NEXT 3984' IS ASPHALT, NEXT 400' IS CONC OVERLAY & GROOVED, REMAINING 1507' IS ASPHALT; REVERSE ORDER FOR RWY 33.
• RADAR: SEE TERMINAL FLIP FOR RADAR MINIMA.
• A-GEAR: RWY 15, HOOK MB60 (35' OVRN)
• A-GEAR: RWY 33, HOOK MB60 (35' OVRN)
• RWY 15/33 70 FT GATED THLD LGT.
• CAUTION: POSSIBLE HYDROPLANING DUR PERIODS OF RAIN ON RWY 15/33 AND LDG ZONE 009-189. LDG ZONE 009-189 IS PAVED.
• CAUTION: UNLGTD TURNAROUND ON E SIDE OF DEP END RY 33/APCH END RY 15 RSTD TO DAYLIGHT VMC EXC FOR APV NGT VISION OPS.
• RSTD: C-5, C-17, KC-10 AND B747 ARE PROH FR 180 DEG TURNS FIRST 200 FT RY 33.
• RSTD: ALL HVY ACFT WILL USE TWY C TO ENTER/EXIT TO AND FR NE.
• RSTD: CTC AIRFIELD MANAGEMENT OPERATIONS DSN 493-6961/62 OR C334-953-6961/62.
• CAUTION: BASH PHASE II BIRD ACTIVITY JUNE - NOV.
• CAUTION: LANDING ZONE 189 OVERRUN EXTENDS ONTO RY 15/33. AIRCREWS USE CAUTION DUE TO LOSS OF WIND SPEED BLO 50' AGL WHEN WINDS BTN 280-310 LDG RWY 15
• AFRC - OPR 1315-2200Z++ WKD, AND UNIT TRNG ASSEMBLY WKEND, DSN 493-2717.
• OPR WKDAYS 1400-0400Z++, WKENDS 1600-2400Z++, CLSD FEDERAL HOL.
• ATIS: 1400-0400Z++ WKDAYS, 1600-2400Z++ WKENDS, CLSD FEDERAL HOL.
• TOWER: 1400-0400Z++ WKDAYS, 1600-2400Z++ WKENDS, CLSD FEDERAL HOL.
• MAXWELL COMBINED COMD POST: MONITOR 118.15 AFTER NML DUTY HRS CALL BAMA-WOLF OPS.
• PMSV: FULL SVC AVBL WKDAYS 1400-0400Z++, WKENDS 1600-2400Z++, CLSD FEDERAL HOL. MAXWELL AFB TAF IS CMPLTD BY 26TH OWS; FOR UPDATED FCST CTC MAXWELL WX OFC AT 334-953-2071. ASOS IN USE, AUGMENTED WHEN NEC DURG AFLD OPR HRS.
• CLASS D SVC 1400-0400Z++ MON-FRI; 1600-2400Z++SAT-SUN CL FED HOLIDAYS OTHER TIMES CLASS E.
• AUGMENTED WX OBSN VIS RSTD TO 1/4-1 NM ALL QUAD EXC NW DUE NUMEROUS OBST. TWR WILL CONDUCT COOPERATIVE WX WATCH AND SUPPLEMENT OBSN AS RQR.
• SERVICE-LGT: RWY 15 - SSALR LGT SYS AVBL DUR VMC COND.
• SERVICE-LGT: RWY 15 PAPI LATERAL COVERAGE LIMITATION SET AT 8 DEG LEFT & 12 DEG RIGHT
• WHEN ATCT CLSD, FOR CD CTC ATLANTA ARTCC AT 770-210-7692.
• ALL AIRCRAFT WITH WINGSPAN GREATER THAN C-130 (132- 7-) ARE RESTRICTED FROM TAXIING TO AND FROM DELTA AND ECHO TAXIWAYS WHEN C-130'S ARE PARKED ON THE WEST RAMP PARKING APRON.
• OVERNIGHT STORE OF CLASSIFIED MATERIAL WILL BE PROVIDED BY MAXWELL COMD POST DSN 493-4747 OR 334-953-7474.
• SEASONAL HRS MONDAY TO THURSDAY 1400-0600Z++ AND FRIDAY 1600-2400++ 1 APR - 30 SEP. 0400-0600Z++ AVBL TO ONLY 908TH FTW ACFT.
• CAUTION - POTENTIAL FOR CAP-USAF ACFT DEPARTURES DUR CLSD AERODROME HRS 0401-1359++ WKD; 0001-1559Z++WKEND.
• TAXIWAY ALPHA FROM NORTH RAMP TO TAXIWAY BRAVO RESTRICTED TO 908TH AIRCRAFT ONLY.
• TAXIWAY ALPHA CLSED FROM RUNWAY 189/009 TO TAXIWAY BRAVO.
• TAXIWAY BRAVO CLOSED FROM RUNWAY 189/009 TO TAXIWAY ALPHA.
• SEASONAL HRS MON TO THU 1400-0600Z++, FRI 1400-0400Z++, WKEND 1600-2400Z++ 1 APR - 30 SEP. 0400-0600Z++ AVBL TO ONLY 908TH ACFT.
• RECTANGULAR 1029 FT AGL, OVERHEAD 1529 FT AGL.
• CLSD FEDERAL HOL.
• PAPI UNUSBL BYD 8 DEGS LEFT & 12 DEGS RIGHT OF CNTRLN.
