Los Alamitos Army Air Field Private

Airport information

ICAO / IATA

KSLI

Coordinates

33.7909, -118.0503

Elevation

32 ft MSL

Magnetic variation

12E

Sectional chart

LOS ANGELES

Airport use

Private

Control tower

Yes

ARTCC

LOS ANGELES (ZLA)

Flight service (FSS)

HAWTHORNE

NOTAM facility

SLI

Attendance

FRI-SUN 1500-2400Z++; MON-THU 1500-0600Z++

Beacon

S-white-green (SS-SR)

Segmented circle

No

Activated

1944/04

Distance from city

1 SE

Communication frequencies

Nearby navigation aids

Approaches

• RNAV (GPS) RWY 22L ↗
• VOR OR TACAN RWY 22L ↗

Departures

• HAWWC THREE (RNAV) ↗

Arrivals

• EMMLN THREE ↗
• EMMLN THREE, CONT.1 ↗
• KAYOH EIGHT ↗
• TANDY SIX ↗
• TANDY SIX, CONT.1 ↗

Minimums & Hot Spots

• TAKEOFF MINIMUMS ↗
• DIVERSE VECTOR AREA ↗

VFR sectional

Open KSLI on the VFR sectional (SkyVector) ↗

Services

Fuel available

Jet A-1 (additive), Jet (JP-8)

Ownership & management

Remarks FAA

• (JOINT FORCES TRAINING BASE JFTB)
• USE 251.15 WHEN LOS ALAMITOS TWR CLSD.
• AIRFIELD MNTNS AN ARFF INDEX A ON A CONS BASIS WITH A TEMPRY INDEX OF B/C CPBLTY BY EXCPN. CTC AIRFIELD OPS NLT 48 HRS FOR CDN.
• RWY-LGTS: RWY 22L - SF.
• RWY-17/35 CLSD (2500X150 ASP).
• JASU - 1(TMD150CIII) 1(AGPU).
• NS ABTMT - PRO IN EFF. ALL DEP RQR BRIEFINGS.
• MISC - WINDS ARE ACCURATE TO WITHIN PLUS OR MINUS 4 KNOTS.
• MISC: TO EXCEED WT BRG CAP CTC AFLD OPS. SEE FLIP AP/1 RTE AND AREA RSTD AND SUPPLEMENT ARPT RMK.
• ARNG AASF OPS- OPR 1530-2330Z++ MON-FRI; EXC HOL. DSN 972-2006, C562-795-2006. HTTP://WWW.CALGUARD.CA.GOV/AASF1.
• RSTD: FOR SPECIAL AFTER HRS LNDG AND AFLD LIGHTING REQUESTS FOR ACFT WEIGHING UNDER 14,500 LBS, CALL AFLD OPS AT 562-795-2571.
• SERVICE: TRAN ALERT - FUEL OPR MON-THU 1430-2330Z++, FRI 1430-0130Z++, CLSD WKENDS AND FEDERAL HOL. EXP CLOSURE OR RDCD SVC PER NOTAM. NO PRIORITY BASIS. EXP SVC DELAYS IF HVY ACFT ARE UTILIZING LAAAF. NO ACFT LAV SVC OR BELT LOAD, CTC AIRSERV AT KLGB 866-247-7378 OR 562-429-8062. LTD TRAN SVC. NO SHUTTLE SVC AVBL.
• CLASSIFIED STOR FOR TSNT AIRCREW UNAVBL AT AFLD MGMT OPS; CTC BASE SECFOR DSN 972-2100, C562-795-2100.
• AIRCREWS UTILIZING LAAAF MUST ADVS THEIR DEP TO LOCAL FSS TO INCL KSLIYXYX AS AN ADDRESSEE ON THE ORIG DD 1801 FLT PLAN AND ON ANY CHG, DELAY, DEP AND CNL MSG.
• ALL TRAN AIRCREWS MUST RPT TO AFLD OPS. HIGH VIS EVENTS (VIP CODE 7 AND ABV) ARE RQRD TO NTFY AFLD OPS 30 MIN PRIOR TO ARR DUE TO POST HQ COORD.
• MISC: AFLD SIGNS NSTD. RWY 04R/22L THLD BARS NSTD. ALL RWY MARKINGS NSTD. TWY AND PRKG LINES NSTD AND NOT VIS IN DARKNESS OR INCLEMENT WX.
• MISC: WILDLIFE HAZ EXISTS; RQRS INCRD VIGILANCE BY ALL AGENCIES AND SUPVRS AND CTN BY AIRCREWS. BASH/WASH COND ANNOUNCED ON ATIS. PILOTS SHOULD RPRT ALL LARGE BIRD AND MAMMAL SIGHTINGS TO TWR OR AFLD OPS.
• FOR CD WHEN ATCT CLSD CTC SOCAL APCH AT 800-448-3724.
• PAR REMOVED FROM SVC, PERMLY CLSD.
• TWY B1 & TWY E LTD TO ACFT 30000 LBS OR LESS.
• CAUTION: FALSE ATC INSTRNS HAVE BEEN RCVD IN THE AREA OF LOS ALAMITOS AIRFIELD; EXER EXTREME CTN ON ALL FREQS AND VFY INSTRNS.
• ALL WHEELED ACFT WILL LAND TO THE RWYS AND GND TAXI TO PRKG ON ALL APCHS AND DEPS UNLESS REQD AND APVD OR DRCTD BY ATC. DSGND HOVERING AREAS ARE RWY 22R RUNUP AREA, TWY E, & TWY F.
• CAUTION: AIRFIELD HAS HIGH POTENTIAL FOR FOD.
• AIRFIELD FOD COND RANGES FROM MOD TO OCNL.
• LAAAF AIRFIELD PROCEDURES GUIDE (APG) AND AIRFIELD OPERATIONS MANUAL (AOM) IS AVBL. IT CAN BE LCTD ON THE CALGUARD SHAREPOINT UNDER CAMP LOS ALAMITOS/JFTB SITES/LOS ALAMITOS ARMY AIRFIELD. CTC BASE OPS FOR A CURRENT COPY NG.CA.CAARNG.MBX.KSLIOPERATIONS@ARMY.MIL OR 562-795-2571.
• PILOTS WILL SMT ALL DD FORM 1801 WITH A NAME IN BLOCK 19, PILOT IN COMMAND (PIC) IAW LAAAF APG, 2-2, B, 3 AND THE GENERAL PLANNER (GP), 4-3, ITEM 19. DD FORM 1801 WILL INCL A CTC NR SEPARATE FROM ANY FLT CREW FOR ANY SEARCH AND RESCUE (SAR) RELATED EMERGS.
• GLARE OBSD FROM SOLAR FARM SITE ON AIRFIELD DRG MIDDAY HRS. PILOTS ARE ADVISED TO RPRT GLARE/GLINT TO ATC TWR UPON OBS.
• ALL FIXED WING HIGH POWER MAINT RUN-UPS MUST BE CONDUCTED ON FAR WEST RAMP FACING TO THE EAST OR ON ACFT STAGING PAD FOR NOISE MITIGATION UFN. ACFT WILL CTC BASE OPS ON 126.2 PRIOR TO ACFT MOV.
• LED LGTG ON AIRFIELD RWYS AND TWYS. LEDS MAY NOT BE COMPATIBLE WITH CERTAIN NGT VISION DEVICES.
• RWY CLEAR ZONES AND ACDNT POTENTIAL ZONES (APZ) CONTAIN LAND USE INVOLVING SUBSTANTIAL HUMAN PRESENCE IN AREAS OF HIGH ACDNT POTENTIALTHAT COULD IMPACT SAFETY OF FLT.
• RWY 04L/22R CLSD TO IFR/NIGHT EXCP VFR/DAY/NVG OPS DUE TO UNAVBLTY OF RWY LGTS.
• RWY 04L & 22R THLD LGTS U/S.
• RWY 22L ALS U/S.
• AD FUEL REQ WILL BE MADE VIA THE FLWG PROCESS: PRI CTC POL (OPS6) ON VHF 126.2, SRY CTC POL 562-795-2149, THIRD CTC BASE OPS 562-795-2571. DUE TO RADIO INTFC, ESTAB CTC ON VHF ON FINAL OR UPON TAX.
• EAST RAMP ACFT GND POINTS NONCOMPLIANT AND UNMARKED.
• AUTOMATED WX BCST SYS NOT AVBL CEILING/VIS AUGMENTATION OF WX OBS WILL NOT BE AVBL AFTER 2300Z MONDAYS, AUTO OBS WILL BE AVBL.
• CLSD ALL FEDERAL HOL. EXP CLOSURE OR RDCD SVC PER NOTAM. RSTD: PPR CTC AFLD OPS, RCMD UNITS ASK FOR CURRENT CPBLTY WHEN REQG PPR DSN 972-2571, C562-795-2571; NG.CA.CAARNG.MBX.KSLIOPERATIONS@ARMY.MIL FOR PPR REQ FORM.
• AIRFIELD OPERATIONS: C562-795-2571/2561
• NATO F24 AVBL.
• HIRL ELEV 1 FT AND LCTD 5 FT FROM EDGE OF RWY.
