Barksdale Air Force Base Private

Airport information

ICAO / IATA

KBAD / BAD

Coordinates

32.5018, -93.6627

Elevation

166 ft MSL

Magnetic variation

2E

Sectional chart

MEMPHIS

Airport use

Private

Control tower

Yes

ARTCC

FORT WORTH (ZFW)

Flight service (FSS)

DE RIDDER

NOTAM facility

DRI

Attendance

ALL ALL

Beacon

S-white-green (SS-SR)

Segmented circle

No

Wind indicator

yes

Activated

1941/05

Distance from city

3 E

Communication frequencies

Nearby navigation aids

Approaches

• HI-ILS OR LOC W RWY 15 ↗
• HI-ILS OR LOC Y RWY 33 ↗
• HI-ILS OR LOC Z RWY 33 ↗
• ILS OR LOC W RWY 33 ↗
• ILS OR LOC Y RWY 15 ↗
• ILS OR LOC Z RWY 15 ↗
• HI-VOR/DME Z RWY 33 ↗
• VOR/DME Y RWY 33 ↗
• HI-TACAN Z RWY 15 ↗
• HI-TACAN Z RWY 33 ↗
• TACAN Y RWY 15 ↗
• TACAN Y RWY 33 ↗

Minimums & Hot Spots

• RADAR MINIMUMS ↗

VFR sectional

Open KBAD on the VFR sectional (SkyVector) ↗

Services

Fuel available

A++

Bottled oxygen

NONE

Bulk oxygen

LOW

Airframe service

MAJOR

Powerplant service

MAJOR

Other services

Cargo

Ownership & management

Remarks FAA

• RSTD: TRAN ACFT WITH ORDNANCE NOT AUTH.
• RSTD: TWYS E & E1 UNLGTD & USABLE FOR DAYLT VFR ONLY.
• BEARING STRENGTH RWY 15-33: ST175, AUW800
• A-GEAR - BAK-12B AVBL UPON REQ 1 HR PRIOR. W SIDE A-GEAR MRK PERM REMOVED. MP EVERY THIRD FRI FR 1200-1400Z++.
• JASU - 1(MA-1A) 7(A/M32A-86) 1(A/M32A-95) 1(A/M32A-60).
• FLUID - W SP PRESAIR LHOX LOX.
• OIL - O-132-133-148-156 JOAP.
• TRAN ALERT - NO PRIORITY BASIS. EXP SVC DELAYS OF 2 HR OR MORE. LTD FLEET SVC AVBL. POTABLE WATER UNAVBL.
• RSTD: 180 DEG TURNS FOR C135 AND HVY ACFT ARE AUTH IN THE FIRST 750 FT RWY 15 AND THE FIRST 1000 FT RWY 33.
• RSTD: PPR REQ NO MORE THAN 7 DAYS PRIOR, NLT 24 HR PRIOR TO ARR. PPR GOOD FOR +/- 15 MIN PPR TIME. COORD OF PPR OUTSIDE OF BLOCK TIME BY FONE IS RQR OR PPR NR WILL BE CONSIDERED CNL.
• TFC PAT - RECTANGULAR 1200 FT, OVERHEAD 1700 FT. VFR COPTER ENTER TFC PAT AT 700 FT FM E AND 1000 FT FM W. OVFT OF MUNITIONS STOR AREA E-NE OF FLD NOT AUTH.
• MISC: ACFT WITH DV CTC PTD OR COMD POST AT LEAST 20 MIN PRIOR TO ETA.
• RSTD: TRNG FOR TRAN AIRCREWS WILL NOT BE PERMS TO INTERFERE WITH LCL ACFT OPR. NON-AFGSC ACFT MAY BE SUBJECTED TO LESS THAN RQR QUANTITY-DISTANCE SEPARATION DUE MUNITIONS OPR. AIRCREWS SHOULD EXER APPROPRIATE RISK MANAGEMENT IN DETERMINING AFLD SUITABILITY. ALL TRAN AIRCREWS MUST RPT TO BASE OPS.
• CAUTION - LGT ACFT AND PRCHT OPS INVOF SHREVEPORT DOWNTOWN 3.3 NM NW DUR FINAL APCH RWY 15 AND DEP RWY 33.
• SERVICE - TRAN ALERT: TRAN MAINT SVC HR 1400-0100Z++ MON-FRI; 1400-2400Z++ SAT-SUN; CLSD HOL.
• SERVICE-LGT: RWY 15 ALSF-1 NSTD CONFIGN - DIST FM THR LGT TO PRE-THR LGT IS 128 FT; PRE-THR LGT TO TERM BAR IS 128 FT.
• MISC: NSTD SPACING OF 150 FT BTN RWY 15 & 33 OVERRUN MRKS.
• ALL TRANS AIRCREWS MUST REPORT TO AIRFIELD OPS.
• RSTD: TWY C UNLGTD, OPEN TO ALL ACFT FOR DAYTIME OPS ONLY EXE FOR B-52.
• MISC: USAF AFLD MGMT PERS DO NOT DETERMINE/RPT A RWY COND CODE (RWYCC) NOR ISSUE FAA FORMATTED FLD COND NOTAM (FICON).
• MISC: AFLD OPS UNA TO ISSUE COMSEC AND HAS NO STORAGE CAPABILITY.
• OPR 1200Z-0630Z++MON-FRI 1400Z-2200Z++WKENDS; CLSD AFGSC FAMILY DAYS AND FED HOL.
• WX DSN 781-3136 OR C318-456-3136.
• ALT #'S 2707/0158.
• BAK-12(B) (1102').
• FIRST 1184 FT RWY 15 AND FIRST 1600 FT RWY 33 CONCRETE. MIDDLE 8972 FT ASPHALT WITH FIRST 3000 FT AT EACH END HAVING A 75 FT WIDE CONCRETE KEEL SFC IN CNTR AND THE MID 2972 FT HAVING A 50 FT CONCRETE KEEL SFC.
