Daniel K. Inouye International Airport

Airport information

ICAO / IATA

PHNL / HNL

Coordinates

21.3184, -157.9257

Elevation

13 ft MSL

Magnetic variation

11E

Sectional chart

HAWAIIAN ISLANDS

Airport use

Public

Control tower

Yes

ARTCC

HONOLULU CONTROL FACILITY (ZHN)

Flight service (FSS)

HONOLULU

NOTAM facility

HNL

Attendance

ALL ALL

Beacon

white-green (SS-SR)

Segmented circle

No

Wind indicator

lighted

Activated

1938/02

Distance from city

3 NW

Communication frequencies

Nearby navigation aids

Approaches

• ILS RWY 08L ↗ · amdt 25A
• ILS Y RWY 04R ↗ · amdt 2A
• ILS Z RWY 04R ↗ · amdt 2A
• RNAV (RNP) RWY 26L ↗ · amdt 0E
• RNAV (RNP) Z RWY 04R ↗ · amdt 2
• RNAV (RNP) Z RWY 08L ↗ · amdt 4
• RNAV (GPS) RWY 04L ↗ · amdt 0C
• RNAV (GPS) RWY 08R ↗ · amdt 1
• RNAV (GPS) Y RWY 04R ↗ · amdt 3A
• RNAV (GPS) Y RWY 08L ↗ · amdt 4
• LOC RWY 04R ↗ · amdt 1D
• LOC RWY 08L ↗ · amdt 2A
• LDA RWY 26L ↗ · amdt 6A
• VOR OR TACAN RWY 04R ↗ · amdt 0E
• VOR OR TACAN-A ↗ · amdt 1D
• VOR OR TACAN-B ↗ · amdt 2D
• KAHE POWER PLANT VISUAL RWY 22L ↗
• WAIALAE GOLF COURSE VISUAL RWY 22L ↗

Departures

• HONOLULU TWO (OBSTACLE) ↗
• HONOLULU TWO (OBSTACLE), CONT.1 ↗
• ALANA TWO ↗
• BANZI ONE (RNAV) ↗
• BANZI ONE (RNAV), CONT.1 ↗
• KEAHI THREE ↗
• KEOLA THREE ↗
• MOLOKAI FIVE ↗
• MOLOKAI FIVE, CONT.1 ↗
• OPIHI THREE ↗
• OPIHI THREE, CONT.1 ↗
• PALAY THREE ↗
• PIPLN ONE (RNAV) ↗
• PIPLN ONE (RNAV), CONT.1 ↗
• SAITO TWO ↗

Arrivals

• BOOKE EIGHT ↗
• INOYI ONE (RNAV) ↗
• INOYI ONE (RNAV), CONT.1 ↗
• JULLE FIVE ↗
• KAENA FOUR (RNAV) ↗
• KLANI FOUR (RNAV) ↗
• KLANI FOUR (RNAV), CONT.1 ↗
• MAGGI THREE ↗
• MAKAH ONE (RNAV) ↗
• OPACA FOUR ↗
• SAKKI FIVE ↗
• SAKKI FIVE, CONT.1 ↗
• SHLAE ONE (RNAV) ↗
• SYMIN ONE (RNAV) ↗

Minimums & Hot Spots

• TAKEOFF MINIMUMS ↗
• DIVERSE VECTOR AREA ↗
• ALTERNATE MINIMUMS ↗
• LAHSO ↗
• HOT SPOT ↗

Airport notices: page 1 ↗

VFR sectional

Open PHNL on the VFR sectional (SkyVector) ↗

Services

Fuel available

100, Jet A, Jet A-1 (additive)

Bottled oxygen

HIGH/LOW

Bulk oxygen

HIGH/LOW

Airframe service

MAJOR

Powerplant service

MAJOR

Parking

tiedowns

Other services

Air freight, Agricultural, Air ambulance, Avionics, Cargo, Charter, Instruction, Rental, Aircraft sales, Survey

Ownership & management

Remarks FAA

• (JOINT BASE PEARL HARBOR-HICKAM)
• PPR FM AMGR FOR TRANSPORATION OF CLASS A OR B EXPLOS IN AND/OR OUT OF HNL.
• DUE TO NON-VISIBILITY TWR UNA TO DTRM IF THE FLWG AREAS ARE CLEAR OF OBSTNS AND/OR TFC: PTNS OF TWY J BTN TWY B & RWY 08R; PTNS OF INTER-ISLAND ACFT PRKG RAMP.
• DUE TO LOCATION OF ATCT, CONTROLLERS UNABLE TO DETERMINE WHETHER ACFT ARE ON CORRECT FINAL APCH TO RYS 04L-04R AND 22L-22R.
• TWYS G ADG V AND BELOW POWER IN W/PPR.
• CAUTION: DURING PERIODS OF REPEATED PRECIPITATION ANTICIPATE WET RY CONDTIONS, IF CURRENT CONDITIONS RQR CONFIRMATION CTC HONOLULU TWR ON INITIAL CONTACT.
• CAUTION: RECREATIONAL BOATING ACTIVITIES ON AND INVOF WATERWAYS.
• MILITARY: ALL MIL ACFT WITH VIP CODE 7 OR ABV CTC 15WG COMMAND POST OR RELAY THRU HF/SSB AWY 1 HR OUT TO CFM BLOCKTIME.
• TFC PAT OVHD ALT 2000 FT, RESTRICTED TO HIANG AND SENTRY ALOHA ACFT.
• MILITARY: ALL MIL ACFT RQR CSTMS/AG/IMG INSPECTION MUST CTC 15WG COMMAND POST OR IF AMC CTC HICKAM AMCC, NLT 3 HRS PRIOR TO ARR WITH DEPARTURE LOCATION, EST BLOCK TIME, NR OF AIRCREW, CIV/MIL PAX, FOREIGN NATIONALS, AND DV CODES.*
• RYS 04W/22W AND 08W/26W RECREATIONAL BOATING ACTIVITIES ON AND INVOF WATERWAYS.
• BIRD STRIKE HAZARD ALL RUNWAYS.
• MILITARY A-GEAR RWY 26R: HOOK MB100(B) (25 FT OVRN).
• MILITARY CAUTION: FOD HAZARD EXISTS ON ALL MOVEMENT AREAS E OF TWY S. FIGHTER AIRCRAFT EXERCISE EXTREME CTN WHEN TAXIING.
• MILITARY CAUTION: A FOD HAZARD EXISTS ON ALL TAXIWAYS AND RUNWAYS BUT ESPECIALLY ON RUNWAY 4L/22R AND TAXIWAYS NORTH OF RUNWAY 8L/26R.
• MILITARY CAUTION: NO FIGHTER TRANSIENT SUPPORT AVAILABLE IN ACCORDANCE WITH ACC LSET FLASH SAFETY 06-02. TRANSIENT FIGHTER UNITS SHOULD PROVIDE THEIR OWN MAINTENANCE SUPPORT.
• MILITARY RSTD: UPON ARR, CREWS WILL PRVD CREW ORDER/EAL TO 647 SFS PATROL AND PROCD DRCTLY TO COMMAND POST (BLDG 2050) AND CMPLT AN OUBD SETUP SHEET TO FACILITATE DEP RQMNTS.
• MILITARY/COMMUNICATIONS: BEDTIME (ALL CORONET W TANKERS USE 311.0 FOR TANKER-FTR INTER-PLANE ON LAUNCH DAY. AFT DUTY HR DSN 448-8888 613AOC/AMD, FLT MGMT).
• MILITARY MISC: WX OPR H24, DSN 449-2251, C808-658-9961.
• MILITARY MISC (2 OF 2 CONT'D): LTD WX BRIEF SUPPORT.REMOTE FLT WX BRIEFINGS CTC 17TH WX SQ H24, DSN 315-449-7950/8333, FAX DSN 315-449-8336; 2 HR PN RQR FOR TIMELY BRIEF.OFFICIAL OBSN TAKEN BY FAA. COOPERATIVE WX WATCH PROCEDURES DO NOT EXIST BTW WX AND ATC.
• MILITARY MISC: NO COMSEC MATERIAL AVBL THRU HICKAM AIRFIELD OPS.
• MILITARY REMARKS: SEE FLIP AP/3 SUPPLEMENTARY APRT INFO, RTE AND AREA RSTD, AND OAKLAND FIR FLT HAZ.
• MILITARY MISC: AFLD OPS DSN 449-0046/0048 FAX DSN 449-7624.
• MILITARY RSTD: TWR APVL RQRD TO USE TWY KILO FROM RWY 4R. HOLD LINE IN EFCT FOR TWY R7 BTN PTN OF TWY XNG APCH ZONE FOR RWY 04L/R. TWY P CLSD TO ACFT OVER 12500 LBS.
• MILITARY SERVICE-A-GEAR: RWY 4R/22L AND 8R/26L SFC GROOVED WITHIN 10 FT OF A-G SYSTEM. POTENTIAL FOR FTR ACFT TAIL HOOK SKIP EXISTS.
• MILITARY MISC 1 OF 2: DUE TO SENSITIVITIES OF CITIZENS, FTR ACFT DEP ONLY AUTHORIZED FR 1700-0700Z MON-SAT, AND 1800-0700Z SUN AND HOL. ALL REQ FOR WAIVERS WILL BE SENT TO THE 15/OG/CC OR 154 OG/CC FOR HIANG AIRCRAFT AT LEAST 5 WORKING DAYS IN ADVANCE.
• MILITARY MISC 2 OF 2: WAIVERS WILL BE GRANTED ON EXTREME NEC. IF SHORT NOTICE MSN ESSENTIAL WAIVERS ARE NEC, CTC 15OG/CC BY FONE THRU 15 WG COMD POST(15 WG/CP) OR 154 OG/CC FOR HIANG AIRCRAFT. 15 WG COMMAND POST WILL PASS APVL TO HICKAM FLT SVC AND HICKAM RAMP ADZY.
• MILITARY TRAN ALERT: 15 WG CAN PROVIDE EQPT BUT CREWS MUST PROVIDE OWN PERS WHEN NEEDED.
• MILITARY RSTD: JBPH-H IS PPR TO ALL NON-TFWC MSN, AMC TRNG MSN AND KC-135 8 UN & 8 EN MSN CALL 735TH MOC AT DSN (315) 499-6970 FOR PPR. ALL AMC PPR WILL BE COORD MON-FRI 1700-0400Z ONLY. ALL NON-AMC ACFT SUCH AS FOREIGN, SISTER SVC, TSNT ACFT, AND OTR MSN MUST CTC 15 OSS/OSA (AMOPS) AT 15OSS.OSA@US.AF.MIL OR COMM 808-789-7215/5932, DSN 315-447-7215/5932, DUTY CELL 808-658-9953 FOR PPR COORD. ALL PPR WILL BE APVD NO EARLIER THAN 72 HR BUT NO LATER THAN 24 HR PRIOR.
• MILITARY RSTD: ALL TRAN ACFT NOT ON AN AMC/TWCF MSN AND HOME STN ACFT TERMINATING AT JBPH-H, WILL PROVIDE A 3 HR OUT CALL (COMM 808-448-6900) AS WELL AS A 20-30 MIN OUT CALL ON 292.5 TO THE 15 WG/CP (KOA CONTROL).
• MILITARY RSTD: MIL ACFT OPR DUR BIRD WATCH COND MODERATE (INITIAL TKOF OR FULL STOP LDG ONLY, NO MULTIPLE IFR/VFR APCH) AND SEVERE (TKOF AND LDG PROH WO 15 OG/CC APVL OR 154 OG/CC APVL FOR HIANG ACFT) CTC HIK RAMP, PTD, 15 WG COMD POST, 735 AMC COMD POST, 154 WG COMD POST FOR CURRENT COND.
• ALL JET ACFT CTC RAMP CONTROL PRIOR TO ENGINE START AT GATE OR HARD STAND.
• WIDE BODY AND 4 ENGINE TBJTS LDG ON RY 04R ROLL TO END OF RY, NO LEFT TURN AT TWY K WO APVL.
• APRON TAXILANE 2 EAST END 360 FT CLSD.
• APRON TAXILANE 6 BTWN TWY C AND SOUTH RAMP CLSD EXCEPT GA/FIXED WING LOADING/UNLOADING ONLY.
• MILITARY SERVICE-FUEL: A++ (MIL; AVBL H24).
• MILITARY MISC: ANG - HI ANG AFLD OPS OPR 1500-0300Z MON-FRI AND UTA WKENDS; CLSD SAT, SUN AND HOL.
• MILITARY MISC: ALL FPL MUST BE FILED WITH PHNL AS DESTN. IF MIL SIDE OF ARPT IS FINAL DESTN, PLACE "DESTINATION HIK" IN RMKS OF FPL. FOR NOTAM USE PHNL IDENT.
• MILITARY RSTD: IF ACFT IS CARRYING HAZ CARGO, CARGO MANIFEST IS ALSO RQRD. AVBL TIMES TO ACCEPT HAZ CARGO ARE 0400-1600Z; ALL HAZ CARGO MUST COORDINATE WITH AMOPS 449-0046/48 48 HRS PRIOR TO MSN.
• CAUTION: HICKAM RAMP TAXI INSTRNS NOT VALID WI PHNL AIRPORT OPERATING AREA (AOA) WHICH INCLS TWYS A, B, PTNS OF TWYS V (SOUTH OF TWY A) AND T, AND ALL RWYS. AIRCREWS MUST CTC HNL TWR OR HNL GND AS DRCTD PRIOR TO ENTERING OR WHILE WI THE PHNL AOA. HICKAM RAMP WILL INSTR ALL ACFT AT THE HAZ CARGO PAD ADJ TO TWY B, TWYS A1-A4, V2-V5 AND PHIK RAMP SIDE PTNS OF TWY T AND V (NORTH OF TWY A).
• LNDG FEE AND STORAGE CHARGES COLLBL ON ARR.
• 2 HRS ADVN NOTICE RQRD OUTSIDE RGLR BUS HRS.
• OVERHEAD TFC PAT ALT 2000' RSTD TO 154 WG (HIANG ) AND 15 WING FTR/C17 AND SENTRY ALOHA ACFT. TFC PATTERN ALTITUDE FOR SMALL ACFT ENTERING FROM NW 800 (787). TFC PATTERN ALTITUDE FOR SMALL ACFT ENTERING FROM S 1000 (987). TFC PATTERN ALTITUDE FOR LARGE ACFT ENTERING FROM S 1500 (1487).
• RWY 8L WIND CONE IN NSTD LCTN.
• MALCOM SMITH OAHU DISTRICT AIRPORTS MGR 808-836-6533; CELL: 808-306-4132; 24/7 ARPT DUTY MGR 808-836-6434.
• NO AGRI OPS (CROP DUSTING) ALLOWED WI CLASS B AIRSPACE.
• BAK-14 BAK-12B (1500').
• BAK-14 BAK-12B(B) (1500').
• 100 OCTANE FUEL AVBL THRU FBO.
• PCR VALUE: 740/F/B/X/T
• PCR VALUE: 852/F/A/X/T
• PCR VALUE: 852/F/A/X/T
• PCR VALUE: 852/F/A/X/T
• RWY 22L PAPI UNUSBL BYD 2 NM.
• RWY 26L PAPI ALIGNED 05 DEG L OF RWY CNTRLN. RWY 26L PAPI UNUSBLE BYD 5 DEG R OF RWY CNTRLN.
• RWY 26R PAPI UNUSBL BYD 1.5 NM FROM THR
• (3) CRANES
